Wall Mounting
2
1
1
Pull down the handset hook until it locks,
so the tab holds the handset.
2
Remove the attached stand.
3
Mount the unit on the wall.
To temporarily place the handset down
during a conversation,
hook it over the top edge of the phone as
shown.
Connection
CAUTION
Ensure the cord is inserted in the groove
to prevent damage to the connector.
To the main unit ( )
The telephone line cord
(included)
< Back view>
TO MAIN UNIT
/PABX
Headset
*
The illustrations used in this page
are a KX-T7730.
–
