Jazzy 1103 Ultra www.pridemobility.com 19
I I I . Y O U R P O W E R C H A I R
Motor Connectors: This is where the controller connects to the motors. The motor connectors are colour-coded with
red and yellow labels. The label colour on the motor connector corresponds with the label colour on the power pod.
Battery Connector: This is where the controller connects to the batteries.
BATTERY CONNECTOR
MOTOR CONNECTOR
Figure 7. Jazzy 1103 Ultra Electrical Components
MOTOR CONNECTOR
POWER POD
MAIN CIRCUIT BREAKER
