Features a hardware tour – Pioneer 50-Disc Magazine DRM-AF751 User Manual
Page 4
4
En
FEATURES
A HARDWARE TOUR
Lock pin
Release
knob
Handle
Electrode
¶ Able to accommodate 50 discs
¶ Disc holder lock/release mechanism
Discs may be locked into position or released by turning the release knob.
¶ Memory
Disc magazines are equipped with memory which makes it possible to read IDs to
identify individual magazines and make the management of offline media easier.
NOTES:
¶ Electrodes are highly susceptible to damage from static electricity, and for this reason
you should always be careful not to allow your hands to come into contact with the
electrodes.
¶ Always be sure to place disc magazines into the provided dust covers when storing
magazines.
