ParaBody Leg Press 100 - Manual (Page 9)

9
STEP 6:
FIGURE 6
• CAREFULLEY slide the SEAT ADJUST (2) into the FRAME (1) and engage the SPRING PIN into one of the adjustment holes.
See FIGURE 6.
• Attach eight PARAGLIDE STRIPS (15) to the inside of the tube on the FRAME (1) using the following steps:
• Thoroughly clean all surfaces where the PARAGLIDE STRIPS (15) are to be attached.
• Remove the PARAGLIDE STRIPS (15) from the paper backing and firmly apply them to all shown surfaces.
• SECURELY assemble one SPRING PIN (16) to the spring pin barrel on the FRAME (1) as shown in FIGURE 6.
1
15
2
16
