Pride Mobility Quantum 6000 - Manual (Page 2)

14”
Front: 5” solid
Rear: 6” solid
Active-Trac
® ATX Suspension with
integrated rear dual-strut suspension
and articulating caster beam
Up to 6.5 mph
1 / Up to 8 mph 1,2
Intelligent Braking
(electronic, regenerative disc brakes)
3.5”
22”
Length: 37” Width: 25.875”
Synergy
® Seat
Adjustable Width: 10”-24”
Adjustable Depth: 10”-24”
TRU-Balance ® 2 Power Positioning System
Adjustable Width: 14”-24”
Adjustable Depth: 14”-24”
High-back Seat (24” x 24”)
4-pole, Hammer Mid-Wheel 6
®
Two 12 volt, deep cycle Group 24
Up to 20 miles
8A, Lester off-board
70A and 100A, PG Remote Plus
70A and 100A, Q-Logic 3
300 lbs. maximum (user weight)
170 lbs.
53.5 lbs. (each)
Lifetime limited warranty on frame
2-year warranty on electronics
18-month warranty on drive motor
DRIvE WHEELS
OMNI-CASTERS
SUSPENSION
MAXIMUM SPEED
BRAkES
GROUND CLEARANCE
TURNING RADIUS 4
OvERALL SIzE 4
SEATING
DRIvE TRAIN
BATTERIES
RANGE PER CHARGE 1
BATTERy CHARGER
AvAILABLE
ELECTRONICS
WEIGHT CAPACITy
BASE WEIGHT
BATTERy WEIGHT
WARRANTy
.
Mid-Wheel 6 ® allows six wheels on the ground
for maximum stability .
Compatible with TRU-Balance ® 2 Power Positioning .
OMNI-Casters (nylon, spherical-shaped casters)
on front and rear prevent wheel hang-ups .
Side-mounted, easily accessible freewheel levers .
ATX Suspension (Active-Trac ® with extra stability)
incorporates front OMNI-Casters for enhanced
performance over more varied terrain .
4-pole Hammer motors .
Accepts (2) Group 24 & (1) NF-22 when used
with a vent tray
.
Solid tires .
Swing-away joystick .
Multi-axis joystick mount .
Elevating leg rests .
Oxygen tank holder .
Neoprene leg rest sleeves .
Gel adductor buttons .
vent tray .
TRU-Balance ® 2 power elevating seat .
Angle-adjustable footplates .
High-mount foot platform .
70° drop-in footrests .
TRU-Comfort TM seating system .
Contoured seating with solid seat pan .
Q-Logic Drive Control System
Specifications Features
FOOTNOTES:
1) Range and speed vary with user weight, terrain type, battery
charge, battery condition and tire pressure.
2) 8 mph with high speed motor package; standard on Group 4
units; optional on Group 3 units
3) 100 amp controller required with high speed motors
4) Due to manufacturing tolerances and continual product
improvement, this specification can be subject to variance
of + or – 3 %.
Options
Shroud Colors
Metallic
Red
Metallic
Blue
Metallic
Black
Sunburst
Orange
(US) 866-800-2002
(Canada) 888-570-1113
www.quantumrehab.com
Q6000-7-19-07
Q6000 3SP - SS (Code: k0856)
Q6000 3MP - SS (Code: k0861)
Q6000 4S - SS (Code: k0868)
Q6000 4S - C (Code: k0869)
Q6000 4SP - SS (Code: k0877)
Q6000 4MP - SS (Code: k0884)
Code Coverage
Metallic
Silver
