- 9 -
System Connections
• Do not connect the power cord until all other connections have been made.
• Remove the jack cover before making any connections.
• Make sure you observe the color cord when connecting audio and video cables.
Connecting to External AV Signal Source
Use the audio and video cables to connect to the AV input jacks on the rear panel of the unit and to
the external AV signal source. Use the S-VIDEO cable to connect the S-VIDEO input jack on the
rear panel of the unit to the external AV signal source.
After connection, turn on the power of the unit and the external AV signal source and then press the
INPUT button to shift to COMPOSITE or S-VIDEO mode.
Note: The L/R audio input jacks can be used in the both COMPOSITE and S-VIDEO modes.
