4
ELECTRIC CONNECTION
NOTE:
In spite of having any kinds of speaker system, must use 4 ohms impedance of speaker
to reduce the distortion during high volume level.
0.5A
3A
FOR 4X7W or 4X25W
FOR 2X7W
RED
YELLOW
BLACK
BLUE
VIOLET
VIOLET/BLACK
FRONT RCA
OUTPUT CABLE (optional)
RCH RED
LCH WHITE
FRONT
RchSPK
REAR
RchSPK
REAR
LchSPK
FRONT
LchSPK
AUTO
ANTENNA
GROUND(B-)
MEMORY (B+)
IGNITION
SWITCH (B+)
ANTENNA CONNECTOR
FUSEBOX
5A
0.5A
(OR 10A)
GREEN
GREEN/BLACK
GREY
GREY/BLACK
WHITE
WHITE/BLACK
GREY
GREY/BLACK
WHITE
WHITE/BLACK
ANTENNA CONNECTOR
IGNITION(B+)
MEMORY (B+)
GROUND (B-)
POWER
ANTENNA
LEFT
SPEAKER
RIGHT
SPEAKER
( FOR RCA LINE-OUT VERSION ONLY)
RCH RED
RCH WHITE
RED
YELLOW
BLACK
(OPTIONAL)
RCA CABLE
(GREY)
BLUE
