Loading Documents
18
4
When using paper longer than the feed
tray, pull out the feed extension tray
from the feed tray and the exit exten-
sion tray as shown in the figure on the
right.
≥ When using small sized documents like
business cards, raise the business card
guides and the business card stopper.
Caution:
Do not use the business card guides and the
business card stopper for larger documents
than their acceptable size. It will cause paper
jams.
5
Place the documents on the feed tray
with the side to be scanned facing up.
≥ Be sure to place the documents on the
feed tray as shown in the figure on the
right.
≥ The amount of documents should not
exceed the limit mark on the document
guide. This may cause a paper jam or
skew.
Feed extension tray
Exit stopper
Exit extension tray
A
Business card guides Business card stopper
Feed tray
Paper feed roller
