TECHNICAL DATA
DIMENSIONS
Height Width Deptth
Height to hotplate 900mm (nominal) 600mm (nominal) 600mm
(to front of
door panel)
Space for fixing at hotplate level 2mm minimum clearance
Space for fixing above hotplate level See important note'Location of Appliance' page 34.
Minimum space above hotplate 787mm (If a cooker hood is fitted refer to the cooker hood
installation instructions).
Weight of appliance 64.5kg.
Minimum distance from rear wall 5mm (spacer given by pressed spacer on vent panel).
CONNECTIONS
Gas Rear left hand side of appliance at hotplate level.
Rc½ (½" B.S.P. female).
Electric None
IGNITION
Spark generator APCO 6BG 6893
Battery 1.5 Volt AA size
GRILL Natural Gas
Heat Input 3.3kW (11263 Btu/h)
Injector Marking 138
HOTPLATE Natural Gas
R.H.F. R.H.R. L.H.R. L.H.F
Heat Input 1.0kW 2.0kW 2.0kW 2.8kW
(3412 Btu/h) (6824 Btu/h (6824 Btu/h) (9554 Btu/h)
Injector Marking 079 104 104 130
MAIN OVEN Natural Gas
Heat Input 2.4kW (8189Btu/h)
Injector Marking 108
Flame Supervision Device Diamond'H' GSD 100/28
Thermostat Diamond'H' 1100-93/B2
Marking 69
GENERAL
Ignition H. T. Spark
Spark Gap 3-4mm
