14
Part Numbers
Item Alpha Code(s) Part Number Description
SA-001 ARL, CLQ, PIR, PIN, APR, ACR AK66-00088-0000 Arm Rest Frame Assembly
SA-002 ARL, CLQ, PIR, PIN, APR, ACR AK66-00084-0000 Arm Rest Pad (2)
SA-003 ARL, CLQ, PIR, PIN, APR, ACR AK66-00133-0000 Arm Rest Support Weldment
SA-004 ARL, CLQ, PIR, PIN, APR, ACR 0K66-01156-0000 Left Arm Rest Shroud
SA-005 ARL, CLQ, PIR, PIN, APR, ACR 0017-00006-0298 Sleeve Bearing (2 total)
SA-006 ARL, CLQ, PIR, PIN, APR, ACR 0K66-01228-0000 Wave Washer (1 per Arm Rest Assy)
SA-007 ARL, CLQ, PIR, PIN, APR, ACR 0K66-01159-0000 Washer (1 per Arm Rest Assy)
SA-008 ARL, CLQ, PIR, PIN, APR, ACR 0017-00100-0256 Retaining Ring (1 per Arm Rest Assy)
SA-009 ARL, CLQ, PIR, PIN, APR, ACR 0017-00101-1891 Pad Mounting Screw (4 per Arm Rest Pad)
SA-010 ARL, CLQ, PIR, PIN, APR, ACR 0K66-01161-0000 Left Bottom Shroud
SA-011 ARL, CLQ, PIR, PIN, APR, ACR 0017-00101-2012 Shroud Mounting Screw (3 per Shroud)
SA-012 ARL, CLQ, PIR, PIN, APR, ACR AK66-00089-0001 Arm Rest with Grip Assy - left
SA-013 ARL, CLQ, PIR, PIN, APR, ACR 0017-00101-1972 Bracket Screw (2)
SA-014 ARL, CLQ, PIR, PIN, APR, ACR 0017-00101-2011 Bracket Screw (2)
SA-041 ARL, CLQ, PIR, PIN, APR, ACR AK66-00137-0000 Bracket And Cable Assembly
SA-042 ARL, CLQ, PIR, PIN, APR, ACR 0017-00101-1881 Arm Rest Support Clamp Mounting Screw (3)
SA-043 ARL, CLQ, PIR, PIN, APR, ACR 0K66-01218-0000 Arm Rest Support Clamp
SA-044 ARL, CLQ, PIR, PIN, APR, ACR 0K66-01162-0000 Right Bottom Shroud
SA-045 ARL, CLQ, PIR, PIN, APR, ACR AK69-00089-0000 Arm Rest with Grip Assy - right
SA-046 ARL, CLQ, PIR, PIN, APR, ACR 0K66-01165-0000 Right Arm Rest Shroud
