Life Fitness Recumbent Exercise Bikes 93Ri User Manual

Page 7

After placing the exercise bike in the intended location for use,
check the stability of the bike. If the exercise bike is not level,
turn a LEVELER (G) in the rear STABILIZER BAR (H) in either
direction until the rocking motion is eliminated. Tighten the
JAM NUT (J) when the exercise bike is level.

NOTE: ONLY ONE LEVELER NEEDS TO BE TURNED.

REMARQUE :

NE TOURNER QU’UN SEUL VÉRIN

10.

Locate the RIGHT PEDAL STRAP (#10) marked with an “R”.
Attach the RIGHT PEDAL STRAP to the RIGHT PEDAL (K)
with the double slot on the inward pedal strap tab looping
upward and attaching to the outward pedal strap tab. Repeat
for the LEFT PEDAL STRAP (#9) marked with an “L”.

Physical Dimensions:

95Ri 93Ri 90R

Length

54 inches / 137 centimeters

Width

26 inches / 66 centimeters

Height

51 inches / 129 centimeters

Weight

134 pounds / 61 kilograms
