Life Fitness X9i - Manual (Page 6)

6
X9i ARCTIC SILVER CROSS-TRAINER X9-0XXX-04
CONSOLE ASSEMBLY S/N AXQ100000 and up
Console Board - Upper
A084-92219-A007
Console Case Assembly
AK63-00121-0001
Battery Door
0K63-01029-0001
Phillips Pan Screws(13)
0017-00101-1650
Bezel/Switch Assembly
AK63-00075-0001
Upper Overlay
Lower Overlay
Switch Membrane
118E-00001-0133
Console Assembly Overlay/Bezel/
Switch Assembly Upper Overlay Lower Overlay
AK61-00193-0001 Eng/Eng AK61-00195-0001 0K61-01382-0001 0K61-01384-0001
AK61-00193-0002 Eng/Met AK61-00195-0001 0K61-01382-0001 0K61-01384-0001
AK61-00193-0003 Ger/Met AK61-00195-0003 0K61-01382-0003 0k61-01384-0003
AK61-00193-0004 Spn/Met AK61-00195-0004 0K61-01382-0004 0K61-01384-0004
AK61-00193-0007 Frn/Met AK61-00195-0007 0K61-01382-0007
0K61-01384-0007
AK61-00193-0008 Itl/Met AK61-00195-0008 0K61-01382-0008 0K61-01384-0008
AK61-00193-0009 Dut/Met AK61-00195-0009 0K61-01382-0009 0K61-01384-0009
AK61-00193-0010 Por/Met AK61-00195-0010 0K61-01382-0010 0K61-01384-0010
