ARCTIC SILVER T9

T9-0XXX-04

Motor Cover, Front Cover & Front End Caps

S/N TTX100000 and up

10-16X 8 PHL PAN
B ST ZS B ( 4 )
0017-00101-1772

GUARD-ASSY: MFG;
RT; 3.50 B
AK58-00360-0001

MOTOR-SHROUD ASSY:
MFG; T9i D
AK60-00163-0000

10-16X 8 PHL PAN
B ST ZB B
0017-00101-1776

GUARD-ASSY: MFG;
LT; 3.50 B
AK58-00360-0002

10-32x10 PHL PAN
MS ST ZS B ( 4 )
AK58-00360-0001

FRONT-PANEL
W/MEDALLION ASSY
AK58-00272-0000

MEDALLION-ASSY:
PURCH;LF-BUG B
AK58-00245-0000

ENDCAP: FRONT
0K58-01267-0000

ENDCAP: FRONT
0K58-01267-0000

10-16X 8 PHL PAN
B ST ZS B ( 4 )
0017-00101-1772
