7
Chapter 3: Getting to Know the Wireless-G Internet Video Camera
Camera Ports
Wireless-G Internet Video Camera
Camera Ports
The Camera features three ports and a Reset button on the bottom panel.
POWER
The POWER port is where you will connect the power adapter.
MIC IN
The MIC IN port is where you will connect the 2.5 mm input jack of your external microphone
(optional).
ETHERNET
The ETHERNET port is where you will connect the Ethernet network cable.
RESET
The RESET button is what you will press if you need to reset the Camera. Insert a paper clip
into the opening next to the Ethernet port. Then press the button and hold it in for five seconds.
IMPORTANT: Resetting the Camera will erase
all of your settings, such as encryption
information, and replace them with the factory
defaults. Do not reset the Camera if you want
to retain these settings.
Figure 3-4: Camera Ports
