Little Wonder HPV 5611 - Manual (Page 19)

17
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
LITTLE
WONDER
HPV
EN
PARTS ASSEMBLY
FIGURE 1
1-1 910914 ENGINE-6HP INTEK 1
1-2 600180.17 DECK-HPV, 6HP 1
1-3 600184.17 HANDLE MOUNT 1
1-4 600187.10 HOUSING-W/LINER HOLE 1
1-5 600114 IMPELLER-BALANCED 1
1-6 600198 PLATE-FRONT 1
1-7 600182.17 BRACKET-FRONT WHEELS 1
1-8 600297 AXLE-FRONT 1
1-9 600298 AXLE-REAR 1
1-10 600137 SPACER-WHEEL 4
1-11 934 WHEEL-10" 2
1-12 920300 WHEEL-12" 2
1-13 600562 RETAINING RING E 5/8 4
1-14 600102 HOSE-NOZZLE 1
1-15 720420 BRIDGE CLAMP-HOSE 2
1-16 600162 KNOB-NOZZLE CNTRL 1
1-17 600104 CABLE-NOZZLE CNTRL 1
1-18 600103 CABLE-THROTTLE CNTRL 1
1-19 600176 CLAMP-BAND 1
1-20 600196 BAG-SEAL STRAP 1
1-21 600177 DEBRIS BAG 1
1-22 64164-13 KEY-1/4" SQ X 2" LG 1
1-23 64123-127 BOLT-3/8-24 X 1-3/4 1
1-24 600504 BOLT-CRG 3/8-16 X 2-1/4 4
1-25 64018-18 BOLT-CRG 3/8-16 X 2 4
1-26 64262-009 BOLT-FLGHD 5/16-18 X 1-1/2 4
1-27 910503
BOLT-5/16-24 X 3/4 4
1-28 64123-113 BOLT-HEX,1/4-20 X 2-1/4 1
1-29 64229-03 LOCKNUT-3/8-16 4
1-30 64141-4 NUT-FLANGE 3/8-16 4
1-31 64229-02 LOCKNUT-5/16-18 9
1-32 64141-6 NUT-FL 5/16-18 6
1-33 64214-01 NUT-WING 5/16-18 1
1-34 64229-01 LOCKNUT-1/4-20 1
1-35 910527 WASHER-FAN 1
1-36 64163--46 WASHER-3/8 ID X 3/16 TH 4
1-37 64163-31 WASHER-3/8 4
1-38 64163-29 WASHER-25/64x1x12GA 8
1-39 64163-55 WASHER-1/4 3
1-40 720411 CABLE TIE-11-5/8 BLK 2
1-41 64268-02 NUT-NYLON LOCK 5/16-18 4
1-42 600604 LABEL-INTAKE WARNING 1
1-43 600602 LABEL-WARNING,HOUSING 1
1-44 600101 ASSY-COLLECTOR 1
1-45 600100 ASSY-NOZZLE 1
