TEMPERATURE RANGE
OPERATION: - 40 o C to +40 o C (- 40 o F to +104 o F)
STORAGE: - 40 o C to +85 o C (- 40 o F to +185 o F)
LN-25
A-1
OPERATING ARC VOLTAGE
Constant Voltage (CV)
or 15-40 VDC (110VDC Maximum OCV)
Constant Current (CC)
RATED CURRENT
Rated current without contactor 500 Amps 60% Duty Cycle
Rated current with contactor 300 Amps 60% Duty Cycle
WIRE SPEED RANGE
50 – 700 Inches Per Minute (IPM)
RECOMMENDED ELECTRODE WIRE SIZES
.023” to 1 ⁄
16
” SOLID STEEL WIRE
.045” to 5 ⁄
64
” CORED WIRE
. 035” to 1 ⁄
16
” ALUMINUM WIRE
PHYSICAL DIMENSIONS
HEIGHT WIDTH DEPTH WEIGHT
(Handle Down) w/o Options
14 Inches 7.4 Inches 21 Inches 28 lbs
(354 mm) (187 mm) (531 mm) (13 kg)
RATED CURRENT
WIRE FEED SPEED
PHYSICAL DIMENSIONS
ENVIRONMENTAL RATING
WIRE DIAMETERS
VOLTAGE
INSTALLATION
TECHNICAL SPECIFICATIONS – LN-25
IP23 (IEC529)
MAR97
