b-9 OPERATION b-9
POWER FEED™ 10M SINGLE WIRE FEEDER
LIMIT SETTING
The MSP4 can be optionally configured to limit the opera-
tor’s range of control of any weld parameter (weld WFS, arc
control, etc.). Limits are only available with the Dual
Procedure/Memory Panel.
MACHINE SETUP/USER PREFERENCES
The MSP4 can be used to configure and troubleshoot the
machine.
ACCESSING THE MACHINE SETUP MENU
To access the Machine Setup menu, press both MSP4 push
buttons simultaneously. The MSP4 7-segment display will
display the first user preference, "P.0", and the SETUP LED
will illuminate.
• Pressing the left MSP4 pushbutton will exit the entire
Machine Setup menu while in the P.0 user preference.
• Turning the MSP4 encoder knob will select other available
User Preferences.
• To exit the User Preference Menu, either rotate the MSP4
encoder until P.0 is displayed and press the left MSP4
pushbutton or press both MSP4 push buttons simultane-
ously at any time.
