Life Fitness CTSX30-0000-01 User Manual
Page 8
8
DC MOTOR
REX01HL
9 VDC
CONSOLE
GND
VCC
REED SWITC
REX01J8H
BLACK
BLACK / WHITE
BLACK
(BLACK) MOTOR+
(BROWN) MOTOR+
(RED) -5VDC
ORANGE
YELLOW
VR
WHITE
YELLOW
WHITE
BLACK
GREEN
RED
BLUE
BLACK
GRAY
TRANSFORMER
REX24ZJ
POWER CABLE
REX01HU
MAIN UPPER CABLE
REX01R
LOWER FRAME CABLE
REX01QT
MAIN UPPER CABLE
REX01R
LOWER FRAME CABLE
REX01QT
LF Sport Consumer Cross-trainer CTSX30-XXXX-01
Block Diagram
