INSTALLATION
A-4
A-4
IDEALARC R3R
TECHNICAL SPECIFICATIONS - IDEALARC R3R-500
INPUT - THREE PHASE ONLY
Standard Voltage
Input Current @ Rated Output
230V
88A
460V
44A
RATED OUTPUT
Duty Cycle
Amps
Volts at Rated Amps
100%
600
44
60%
500
40
35%
375
35
OUTPUT
Current Range
Maximum Open Circuit Voltage
75 to 625 Amps
67 VDC
RECOMMENDED INPUT WIRE AND FUSE SIZES AT 60% DUTY CYCLE
Input Wire Size
Ground Wire Size
Input Voltage /
Fuse
Input Ampere
Type 75°C
Type 75°C
Frequency
(Super Lag)
Rating on
Copper Wire in
Copper Ground
or Breaker Size
Nameplate
Conduit
Wire in Conduit
Volts/Hz
AWG (IEC) Sizes
AWG (IEC) Sizes
230/60
150
88
4 (25 mm
2
)
6 (16 mm
2
)
460/60
70
44
8 (10 mm
2
)
8 (10 mm
2
)
PHYSICAL DIMENSIONS
Height
Width
Depth
Weight
27.50 in.
22.25 in.
33.10 in.
446 lbs.
(700 mm)
(565 mm)
(840 mm)
(202 kg)
