P/No.3828FW3144A
5
Control panel
1. Water Inlet
Connect the hose from the water faucet to feed water to the tub.
2. Wash Timer
Used to select the desired time for washing or rinsing.
3. Drain Selector
Select "WASH · RINSE" for washing and rinsing, and "DRAIN" to drain the tub.
4. Spin Timer
Used to select the desired time for spinning.
WASH TIMER
DRAIN SELECTOR
WASH.RINSE
9
SPIN TIMER
OFF
1
2
4
5
3
DRAIN
OFF
3
6
12
15
4
3
2
1
SPECIFICATIONS
Power source
On SPECIFICATION LABEL
Water level
High : 34
L
Water pressure
Less than 100kPa (1kgf/cm
2
)
Dimensions
686
Ч
412
Ч
835mm. (W
×
D
×
H)
Weight (Net)
17kg
H
D
W
