LTRx-512 User’s Guide
Keypad Commands
Quick Check Command [*] Status
This “Quick Check” command displays system information for about two (2) seconds
Any time you see the time and date displayed, you can press [*] to see the Master status. You
will see the firmware version, terminal ID#, communications baud rate, time display format
(12-hr or 24-hr), daylight savings country code and the clock types set with your system
When you press [*], you will see a display similar to
04-03-03 VER.2.11
ID# 065 | BAUD 9600
TIME 12HR | DST 08
CLK1 01 | CLK2 00
Display Description
V1.06 Firmware version
ID# Terminal ID# **
BAUD Baud rate for network communications **
TIME Shows if display is in 12-hr or 24-hr format
DST Daylight savings time country code
CLK1 | CLK2 Clock types that will synchronize
** (LTR8-512 & LTR8-512M only)
If you need to call Tech Support, please have the above information available, as well as the
serial number of the unit
Quick Check Command [1] Edit Keys
This “Quick Check” command displays system information for about two (2) seconds
Any time you see the time and date displayed on the Master, you can press [1] to see the edit
key descriptions. You can use the edit keys to program Bell Schedules, Automatic Schedule
Change Dates, and Holiday Dates. When you press [1], you will see
