Page 7
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 7350701 ASSY, HEAD PLATE (14)
2 14 7328401 WEIGHT PLATE, 20 LB
3 1 7327601 ASSY, INCREMENT WT - 5LB
4 1 7327701 ASSY, INCREMENT WT - 10LB
5 1 7327801 ASSY, INCREMENT WT - 15LB
6 2 7328701 SPACER, INC WT STACK - 14 PLT
7 2 7351001 SPACER, INC WT STACK
8 1 7621101 RETAINER, GUIDE ROD - TOP
9 4 7328610 GUIDE ROD, .75 OD SOLID 39.75
10 4 7337901 BUSHING, GUIDE ROD
11 4 7352101 CUSHION, WEIGHT STACK
12 4 3103301 SHAFT COLLAR, 3/4 I.D. ZINC
13 1 7592301 COVER, TOWER- BOTTOM FRONT HAD
14 1 7592401 COVER, TOWER- BOTTOM REAR HAD
15 1 7318601 COVER, TOWER- TOP FRONT
16 1 7318701 COVER, TOWER- TOP REAR
17 1 7765701 SHROUD, TOWER- REAR SHORT
18 2 7765601 SHROUD, TOWER- FRT SHORT RH
19 2 7326301 CAP, D-TUBE - BOTTOM
20 6 7583501 RETAINER, FZ SHROUD
21 2 3236202 SCREW, M10 X1.5 25MM
22 13 3239101 SCREW, M5X10 PHL PAN TT ST
23 9 3236501 M4 X 0.7 PHL PAN MS ST ZN
MID-14 TOWER HAB/HAD ASSEMBLY LEGEND
FZHAD HIP ADDUCTION
