Page 3
ž PAGE − 3
When Vendor ID, Device ID, Device Class or IRQ aren’t displayed or an error occurs,
please change the PCI slot.
After correct hardware installation you can start installing the software from the driver
CD.
u
Pin Assignments
Parallel 25 Pin female connector pin assignments:
Parallel 25 Pin female connector :
Pin
Signal
Pin Signal Pin
Signal
1 STROBE 10
ACKNOWLEDGE 19
GROUND
2 DATA
0 11
BUSY
20
GROUND
3
DATA 1
12
PAPER EMPTY
21
GROUND
4 DATA
2 13
SELECT
22
GROUND
5
DATA 3
14
AUTO FEED
23
GROUND
6 DATA
4 15
ERROR
24
GROUND
7 DATA
5 16
INIT
25
GROUND
8
DATA 6
17
SELECT INPUT
26
GROUND
9 DATA
7 18
GROUND
Serial 9 Pin male connector pin assignments:
Serial 9 Pin male connector :
Pin Signal Pin Signal Pin Signal Pin
Signal
1 CD 4 DTR 6 DSR 8
CTS
2 RD 5
GROUND
7 RTS 9 RI
3 TD
u
Technical Specification
Compatibility:
PCI 32Bit card for 486/586/Pentium/Pentium-II/
P-III/C5/K6
Operating system:
WIN 9.x/ME/NT/2000/XP, LINUX, DOS
Chips:
1 x SUN1889, 1 x SUN1689
Connections:
2 x DB 9 m connector serial
1 x DB 25 B f connector parallel
PCB:
2 Layer / 120 x 76 mm
