1
Base, Load Bank
M18720
1
X
2
Side Panel, (Left)
M18720-1
1
X
3
Side Panel, (Right)
M18720-2
1
X
4
Venturi, Fan
M18720-3
1
X
5
Rail (For Relay K8 Mtg.)
M18720-62
1
X
6
Pan, Relay
M18720-5
1
X
7
Panel, Screened
M18720-6
2
X
8
Cover. Load Bank
M18720-7
1
X
9
Cover. Res Element
M18720-8
2
X
10 Terminal Board {RB}
M18720-9
1
X
11 Terminal Board {RA}
M18720-10
1
X
12 Resistance Element
M18720-11
6
X
13 Resistance Element
M18720-12
3
X
14 Resistence Element
M18720-13
12
X
15 Rod, Element Support
M18720-14
21
X
16 Bus Link
M18720-15
28
X
17 Plate Identification
M18720-16
1
X
18 Relay (K8)
M18720-61
1
X
19 Label Warning
M18720-58
1
X
20 Label Warning
M18720-59
2
X
21 Label Warning
M18720-60
1
X
22 Plate, Designation (L1,L2,+,-)
M18720-21
1
X
23 Plate, Designation (GND)
M18720-22
1
X
24 Line Cord {P1}
M18720-23
1
X
25 Control Panel
M18720-24
1
X
26 Schematic/Wiring Diagram
M18720-25
1
X
27 Relay {K1-K4}
M18720-26
4
X
28 Relay {K5}
M18720-27
1
X
29 Support, Motor
M18720-28
1
X
30 Terminal Connector {W1, W2}
S16656-4
2
X
31 Relay {K6, K7}
M18720-29
2
X
32 Fuseholder {XF1 - XF3}
M18720-30
1
X
33 Fuse, 15A {F1}
M18720-31
1
X
34 Motor, 1/4 HP, 120V {B1}
M9983-4
1
X
35 Fuse, 3A {F2.F3}
M18720-32
2
X
36 - -
37 Caster, Swivel
M18720-34
2
X
38 Impeller, Fan
M18720-35
1
X
39 Tube, Steatite
M18720-36
210 X
40 Molding
M18720-37
AR
X
41 Transformer, Current {CT1}
M18720-38
1
X
42 Bus Bar
M18720-39
1
X
43 - -
44 Caster, Rigid
M18720-41
2
X
45 Pin, Spring Clip
M18720-42
42
X
46 Grommet
M18720-43
1
X
47 Cover
M18720-63
1
X
48 Nut, Jam
M18720-64
1
X
* Recommended Spare Part
3-18-97
Use only the parts marked
“
x
”
in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
ITEM DESCRIPTION
PART NO.
QTY.
1 2 3 4 5 6 7 8 9
