Good, reliable operation with a minimum of service starts with attention to the small details:
1. Setting the nozzle position and electrodes "by the book" using the manufacturer's gauges.
2. Installing a quality micron filter at the burner.
3. Making careful/tight flare connections without couplings on oil suction line.
4. Checking fuel pump pressure.
5. Checking draft at the breeching to insure it is adequate to overcome flue gas resistance.
6. Setting the air band properly with well maintained instruments. A good target is 11% to 12.5% of (CO
2
) or 6.5%
to 3.8% of (O
2
).
Note: Oil and Gas burners on B40-series boilers cannot be properly commissioned
without instruments and gauges.
The following information applies only to the BIASI B-40 series boilers at a maximum output
for power venters or lined chimneys only.
8. Burner Setup:
BURNER MANUFACTURER
Heatwise
Boiler Model
B-406
B-407
B-408
B-409
B-410
B-411
B-412
Burner Model
P2-KA
P2-K
P2-K
DE-10
DE-10
DE-10
DE-10
Firing Rate
2.2 GPH
2.8 GPH
3.5 GPH
4.25 GPH
5.0 GPH
5.7 GPH
6.4 GPH
Insertion Depth
FULL
FULL
FULL
FULL
FULL
FULL
FULL
Nozzle
2.00 X 45
2.25 X 60
2.75 X 60
3.25 X 60
3.75 X 60
4.5 X 45
5.50 X 45
Spray Pattern
solid
solid
solid
solid
solid
solid
solid
Pump Pressure
140 psi
170 psi
175 psi
175 psi
175 psi
160 psi
140 psi
Head Position
12
16
18
1
1.5
2
2.5
Air Setting
11.50
15.00
18.00
3.5
4.5
5.5
6.75
BURNER MANUFACTURER
Riello
Boiler Model
B-406
B-407
B-408
B-409
B-410
B-411
B-412
Burner Model
F-10
F-10
F-15
F-15
F-15
F-20
F-20
Firing Rate
2.4 GPH
2.6 GPH
3.3 GPH
4.0 GPH
4.6 GPH
5.3 GPH
5.9 GPH
Insertion Depth
4.5"
4.5"
4.5"
4.5"
4.5"
4.5"
4.5"
Nozzle
2.00X60
2.00X60
2.50X60
3.00X60
3.50X60
4.0X60
4.5X60
Spray Pattern
B
B
B
B
B
B
B
Pump Pressure
145 PSI
175 PSI
175 PSI
175 PSI
175 PSI
175 PSI
175 PSI
Turbulator
3.75
4.5
1.8
2.1
2.8
3.1
5
Air Gate
5
6
3
4
5.5
4
6
BURNER MANUFACTURER
Beckett
Boiler Model
B-407
B-407
B-408
B-409
B-410
B-411
B-412
Burner Model
CF 375
CF 375
CF 500
CF 500
CF 800
CF 800
CF 800
Firing Rate
2.1 GPH
2.7 GPH
3.2 GPH
3.7 GPH
4.3 GPH
4.8 GPH
5.3 GPH
Insertion Depth
4.5"
4.5"
4.5"
4.5"
4.5"
4.5"
4.5"
Nozzle
1.75X60
2.00X45
2.75X45
2.75X45
3.25X45
4.0X30
4.0X30
Spray Pattern
ES
hollow
solid
solid
solid
solid
solid
Pump Pressure
140 psi
180 psi
140 psi
180 psi
175 psi
145 psi
180 psi
Head Type
Head Position
0
2
3
4.5
3
3
4.5
Air Setting
9/0
3/1
7/0
10/0
7/0
8/0
10/2
