Specifications, Wireless home audio – Linksys Director / Wireless-N Music Player DMC250 User Manual
Page 55

Specifications
48
Director/Wireless-N Music Player with Integrated Amplifier
Wireless Home Audio
Specifications
Model
DMC250
WiFi Standards
Draft Dual Band 802.11n,
802.11g, 802.11b
(2.4 GHz and 5 GHz)
Security features
WEP, WPA, WPA2
Security key bits
64, 128, 256
# of Antennas
Internal Antennas Only
Detachable (y/n)
N
RF Pwr (EIRP) in dBm 11b=17dBm, 11g/n=16dBm
Antenna Gain in dBi
3.7 dBi (2.4 GHz), 4.7 dBi (5 GHz)
UPnP able/cert
UPnP Certified
Output Power Specs / THD + N
2 x 60W RMS / 4 Ohm / 0.5%
THD+N / 20Hz-20kHz
(FTC = Both Channels Driven and
Full Freq. Range)
70W RMS / 4Ohm / 0.5% THD+N.
/ 1kHz. Power Bandwidth
20Hz-20kHz (DIN = One Channel
Driven and Power BW at -3dB)
Ports
3.5mm Stereo Headphone
Output, RJ-45 Connector
(Ethernet), USB 2.0 A-Connector,
iPod Astron Connector, 2x2/L-R
Speaker Wire out, RCA L/R
Input, RCA L/R Output, S/PDIF
(Toslink) Output, AC In,
Subwoofer RCA Output
Buttons Front
Power (Standby), Touch-Wheel
Volume Control, Four Soft button
LCD Interface
Buttons Rear
WPS Button
Display
Display Size: 3.5 inches,
Resolution: 320x240, LCD Type:
TFT Transmissive, Color: 262K,
Back Lighting: White LED,
Module Size: 76.8W x 63.8H x
3.3D mm
LEDs
One Blue LED indicating unit
is ON. One Orange LED
indicates STANDBY.
On connection to the Network,
Blue LED will blink. On no power
application, no LED.
Power supply
16W/105W Internal Power
Supply
Cables
Ethernet Cable, 6’ RCA Stereo
Audio Cables, AC Region Cable
Media playback formats / Rates
Output Sample Rates 8.0 kHz, 11.05 kHz, 12.0 kHz,
16.0 kHz, 22.05 kHz, 24.0 kHz,
32.0 kHz, 44.1 kHz, 48.0 kHz
Audio Codecs
w/ Input bitrates
MPEG-1 Audio Layer 3
(MP3)
32, 40, 48, 56, 64, 80, 96, 112, 128,
144, 160, 192, 224, 256 and
320 kbit/s
AAC-LC
64, 96, 126, 256, 320 kbits
WMA9
64 to 192 kbit/s
WAV
Bitrates from 16kbit (8 kHz Mono)
to 1.92 mbit (48 kHz Stereo)
Containers Supported MP4 containing AAC-LC media.
M4A containing AAC-LC media.
ASF containing WMA9 media
Environmental
Dimensions
6.34" x 5.73" x 6.94" (H x W x D)
161 x 146 x 176 mm
Weight
3.42 lb (1.55 kg)
Power
90-264Vac, 50-60Hz
Certification
FCC, CE, TUV
Operating Temp.
32 to 104°F (0 to 40°C)
Storage Temp.
-4 to 158°F (-20 to 70°C)
Operating Humidity
10 to 85% Noncondensing
Storage Humidity
5 to 90% Noncondensing
Specifications are subject to change without notice.
