MTSFP FRONT PULL DOWN

SEAT AND THIGH ASSEMBLY LEGEND

ITEM NO.

QTY.

PART NO. DESCRIPTION

1

1

7459701

WLDMT, MTFP, SEAT FRAME

2

2

7359701

SEATRACK FRONT

3

2

3102801

NUT, NYLOCK 1/2-13 ST ZN

4

2

3239311

1/2-13 X 2.75 UNS HEX FHB G5 ZN

5

1

7463701

WLDMT, MTS, THIGH HOLD DOWN

6

3

7352201

CAP, END 1-1/2 X 2

7

1

7359301

.75" SS ROUND SEAT PIN

8

2

3103301

SHAFT COLLAR, 3/4 I.D. ZINC

9

1

3235801

GRIP, SHADOW GRAY, 3.5"

10

1

7662901

CAP, GRIP

11

1

7564301

SEATRACK, SERRATED

12

1

7564401

SEATRACK, FLAT

13

1

3236801

NUT, M10 HEX NYLOCK SS

14

1

3238312

M10x1.5x75mm

15

1

3236211

SCREW, M10 X1.5 70MM

16

1

7464301

ASSY, MTS, 83 SEAT

17

1

7422001

LABEL, SEAT INST

18

1

7422002

LABEL, SEAT ADJUST

19

1

7442601

SPRING, PRO2 ROLLER SEAT

20

2

3247701

M4 X .7 HXS NO CUP ST BO

21

1

7570601

STOP, ROLLER SEAT

22

1

3235802

GRIP, SHADOW GRAY, 1.5"
