631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • D0211
Lytecaster Performance Recessed Downlighting
1001H
Page 2 of 2
5" Aperture Horizontal Open, Performance Series, Reflector Trim
Job Information
Type:
70W ED-17 COATED LAMP HID, LUMEN RATING = 5700 LMS, CL FINISH TRIM
60˚
30˚
Coefficients Of Utilization
Ceiling
80%
70%
50%
30%
0
Wall
70 50 30 10 50 10 50 10 50 10
0
RCR
Zonal Cavity Method - Effective Floor Reflectance = 20%
Room Cavity Ratio
0 58 58 58 58 57 57 55 55 52 52 49
1 55 53 52 50 52 50 50 48 48 47 44
2 51 48 46 43 47 43 46 42 44 41 39
3 48 44 40 38 43 38 41 37 40 36 35
4 44 39 36 33 39 33 38 33 37 32 31
5 41 36 32 29 35 29 34 29 33 29 28
6 38 33 29 26 32 26 31 26 31 26 25
7 36 30 26 24 30 23 29 23 28 23 22
8 33 28 24 21 27 21 27 21 26 21 20
9 31 25 22 19 25 19 25 19 24 19 18
10 29 24 20 18 23 18 23 18 22 18 17
Determined In Accordance With Current IES Published Procedures
Luminaire Input Watts = 33.0
Candlepower Distribution
0
45
90
0
1494
1494
1494
5
1496
1509
1526
10
1426
1495
1565
15
1335
1452
1545
20
1255
1406
1512
25
1184
1346
1446
30
1032
1156
1287
35
1826
1587
1577
40
800
835
843
45
714
747
772
50
608
681
739
55
460
557
603
60
78
84
97
65
15
13
15
70
13
3
9
75
12
5
9
80
6
6
0
85
0
0
0
90
4
3
0
Trim/Frame:
1001HCL HID
Lamp lumens:
5700 lm
Input Watts:
81W
Efficiency:
49.0 %
Spacing Criterion (0-180):
1.08
Spacing Criterion (90-270):
1.24
Multiple Unit Data - RCR 2
Spacing
Avg.Initial
Watts/
On Ctr.
Footcandles
Sq. Ft.
6'
69
2.01
8'
48
1.40
10'
30
0.90
38'x38'x10' Room, Workplane 2 1/2'
above floor, 80/50/20% Reflectances
Zonal Lumens And Percentages
Zone
Lumens
%Luminaire
0-30
1157
41.0%
0-40
1766
63.0%
0-60
2763
99.0%
0-90
2800
100.0%
26W TRIPLE TUBE LAMP, LUMEN RATING = 1710 LMS, ELECTRONIC BALLAST, CL FINISH TRIM
1
2
150
300
450
600
60˚
30˚
COEFFICIENTS OF UTILIZATION
Ceiling
80%
70%
50%
30%
Wall
70 50 30 10 50 10 50 10 50 10
0
RCR
Zonal Cavity Method - Effective Floor Reflectance = 20%
Room Cavity Ratio
0 69 69 69 69 68 68 65 65 62 62 58
1 65 63 61 60 62 59 60 57 57 55 53
2 61 57 54 52 56 51 54 50 52 49 47
3 56 52 48 45 51 44 49 44 48 43 41
4 52 47 42 39 46 39 45 39 43 38 37
5 49 42 38 35 42 35 41 34 40 34 32
6 45 39 34 31 38 31 37 31 36 30 29
7 42 35 31 28 35 28 34 30 27 33 26
8 39 33 28 25 32 28 25 31 28 25 24
36 37 30 26 23 30 26 23 29 25 23 22
10 35 28 24 21 28 21 27 23 21 26 20
Determined In Accordance With Current IES Published Procedures
Luminaire Input Watts = 26
ZONAL LUMENS AND PERCENTAGES
Zone
Lumens %Lamp
%Fixt
0-30
409.25
23.9
41
0-40
614.89
36
61.7
0-60
989.42
57.9
99.2
0-90
997.25
58.3
100
90-120
0
0
0
90-130
0
0
0
90-150
0
0
0
90-180
0
0
0
0-180
997.25
58.3
100
** Efficiency = 58.3% **
ZONAL LUMEN SUMMARY
Zone
Lumens
0-10
51.35
10-20
148.05
20-30
209.85
30-40
205.64
40-50
204.86
50-60
169.66
60-70
.7
70-80
.8
80-90
.03
90-100
0
100-110
0
110-120
0
120-130
0
130-140
0
140-150
0
150-160
0
160-170
0
170-180
0
SC = 1.1
1 = 90˚
2 = 0˚
CERTIFIED TEST REPORT NO. 3181FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
CANDLEPOWER SUMMARY
Angle
0˚ CP
90˚ CP
0
538
538
5
518
561
10
506
564
15
479
561
20
454
535
25
434
494
30
380
431
35
314
347
40
279
273
45
271
255
50
259
261
55
217
231
60
25
42
65
3
4
70
1
2
75
1
1
80
0
0
85
0
0
90
0
0
500
1000
1500
0
500
1000
1500
Single Unit Data
Height to
Initial
Beam
Lighted Plane
Footcandles
Diameter
6'
42
6'
8'
23
8'
10'
15
11'
12'
10
13'
