C-1 ACCESSORIES C-1
LN-15 CONTROL CABLE MODEL (CE)
WIRE TYPE ELECTRODE SIZE KP KIT
Steel Wires: .023-.030" (0.6-0.8mm) KP1696-030S
(Including stainless steel) .035" (0.9mm) KP1696-035S
.040-.045" (1.0-1.2mm) KP1696-045S
.052" (1.4mm) KP1696-052S
.035-.045" (0.9-1.2mm) KP1696-1
.040" (1.0mm) KP1696-2
Cored Wires: .030-.035" (0.8-0.9mm) KP1697-035C
.040-.045" (1.0-1.2mm) KP1697-045C
.052" (1.4mm) KP1697-052C
1/16" (1.6mm) KP1697-1/16C
.068" (1.7mm) KP1697-068
5/64" (2.0mm) KP1697-5/64
Aluminum Wires: .035" (0.9mm) KP1695-035A
.040" (1.0mm) KP1695-040A
3/64" (1.2mm) KP1695-3/64A
OPTIONAL EQUIPMENT
• K1797-[ ] control cable extensions
• K1798 Adapter Cable for Control Cable to Terminal
Strip Power Sources
• K1500-1, -2, -3, -5 Gun Receiver Bushings
• Drive Roll Kits (Include drive rolls and guide tube necessary to feed the identified wire
size and type.
