LG LS122CE User Manual
Page 20
20 Room Air Conditioner
Installation
Reroute the pipings and the drain hose across the back of the chassis.
Reroute the pipings and the drain hose across the back of the chassis.
Drain hose
Vinyl tape(narrow)
Pipe
Wrap with
vinyl tape(wide)
• Bundle the piping and drain hose together by wrapping them with cloth tape over the range within which they
fit into the rear piping housing section.
Piping for
passage through
piping hole
Drain hose
Connecting
cable
