Service Manual 79
Replacement Parts List
Parts List (Indoor)
NOTE)
*
Please ensure GCSC since these parts may be changed depending upon the buyer's request.
(GCSC WEBSITE http://biz.LGservice.com)
PART No.
LSN180CE
LSN240CE
LSN180HE
LSN240HE
131410
CHASSIS ASSEMBLY
3141A20020G
3141A20020G
3141A20020G
3141A20020G
R
135311
GRILLE ASSEMBLY, DISCHARGE(INDOOR)
3531A20252Y
3531A20252Y
AEB30240201
AEB30240201
R
135312
GRILLE ASSEMBLY, FRONT(INDOOR)
3531A23005R
3531A23005R
3531A23005R
3531A23005R
R
135516
COVER ASSEMBLY, MOTOR
3551A20154A
3551A20154A
3551A20154A
3551A20154A
R
146811
MOTOR ASSEMBLY, STEP
4681A20055A
4681A20055A
4681A20055A
4681A20055A
R
152302
FILTER(MESH), A/C
5230A20052B
5230A20052B
5230A20052B
5230A20052B
R
152312
FILTER ASSEMBLY
5231A20040B
5231A20040B
5231A20040B
5231A20040B
R
159901
VANE, HORIZONTAL
5990A20071A
5990A20071A
5990A20071A
5990A20071A
R
249951
CONTROL BOX ASSEMBLY,INDOOR
4995A10205B
4995A10205E
4995A10205E
4995A10205E
R
263230
THERMISTOR ASSEMBLY
6323A20004N
6323A20004N
6323A20004N
6323A20004N
R
267110
REMOTE CONTROLLER ASSEMBLY
6711A20128A
6711A20128A
6711A20128C
6711A20128C
R
268712
PWB(PCB) ASSEMBLY, DISPLAY
6871A20681F
6871A20681F
6871A20681D
6871A20681D
R
268714
PWB(PCB) ASSEMBLY, MAIN
6871A20771A
6871A20771D
6871A20771D
6871A20771D
R
342800
BEARING
4280A20004A
4280A20004A
4280A20004A
4280A20004A
R
346810
MOTOR ASSEMBLY, INDOOR
4681AR2295M
4681AR2295M
4681AR2295M
4681AR2295M
R
35211B
TUBE ASSEMBLY, TUBING
5211A21378C
5211A21378D
5211A21378D
5211A21378D
R
354210
EVAPORATOR ASSEMBLY, FIRST
5421A20220A
5421A20220A
5421A20220A
5421A20220A
R
359011
FAN ASSEMBLY, CROSS FLOW
5901A92441E
5901A92441E
5901A92441E
5901A92441E
R
668713
PWB(PCB) ASSEMBLY, SUB
6871A20990G
6871A20990E
6871A20990D
6871A20990D
R
733010
PLATE ASSEMBLY, INSTALL
3301A20020B
3301A20020B
3301A20020B
3301A20020B
R
DESCRIPTION
REMARKS
LOCATION
No.
