14
STEP 11:
FIGURE 11
• Insert the LEFT BAR SUPPORT (12) into the desired slots of the LEFT ADJUSTMENT RACK (10), and allow it to drop down to lock in
place. See FIGURE 11.
10
13
12
• Repeat the above step to assemble the RIGHT BAR SUPPORT (13) to the RIGHT ADJUSTMENT RACK (9).
9
7
Thank you for purchasing the OLYMPIC HEAVY DUTY MULTI RACK. If unsure of proper use of
equipment, call your local Hammer Strength distributor .
SERIAL NUMBER
• Insert the BAR CATCHES (14) into the desired slots on the LEFT & RIGHT ADJUSTMENT RACKS (10 & 9) and (16 &17), and allow
it to drop down and lock into place. See FIGURE 11.
14
14
16
