Introduction
1-8 Issue 1 June 1998
Table 1-1. Switch Module Specifications
Specification Description
Size 8” x 8” x 1 ½”
(205 mm x 205 mm x 40 mm)
Weight 1.5 pounds (0.68 kilograms)
Power Requirements 12 vdc supplied by 120 VAC adapters.
800 mA maximum
Approvals UL
CSA
FCC Class A
Communication
Data Type V.34 compression
Data Impedance 600 Ohms
Data Tx Level –15 dBm (+1 dBm/–3 dBm)
Data Rx Sensitivity –40 to 0 dBm
User Data Port
Data Type RS-232D
Data Rate Setting 115.2 kbps, 57.6 kbps, 38.4 kbps,
19.2 kbps, 9.6 kbps, 4.8 kbps, 2.4
kbps
Parity Setting None, Even, Odd
Data Bits Setting 7, 8
Stop Bits Setting 1 or 2
