STEP 2:

FIGURE 2

5

• SECURELY assemble two DUMBBELL CHANNELS (3) to the FRAME (1) using six BLACK RH CAPS (9), three 3/8 X 3-3/4”

BOLTS (5), six 3/8” SAE WASHERS (7), six 3/8” RH WASHERS (8) and three 3/8” LOW HEIGHT LOCK NUTS (6) as shown
in FIGURE 2.

3

8

1

6

9

3/8 X 3-3/4” 5

7
