Lochinvar Copper-Fin2 CP 501 - 751 User Manual
Page 3
ITEM
NO.
PART NO.
DESCRIPTION
MODEL NO.
BURNERS
GAS TRAIN ASSEMBLIES
2
ORF2050
NATURAL GAS ORIFICE
CPN501-751
2
ORF2051
LP GAS ORIFICE
CPL501-751
3
VAL2412
NATURAL GAS VALVE ASSEMBLY
CPN501-751
3
VAL2413
LP GAS VALVE ASSEMBLY
CPL501-751
CONTROLS & GAUGES
4
PAN3021
COMPLETE CONTROL PANEL BEGINNING SERIAL # F0600187510
ALL
4
PAN3017
COMPLETE CONTROL PANEL BEFORE SERIAL # F0600187510
ALL
5
RLY2904
ELECTRONIC CONTROL BEGINNING SERIAL# F0600187510
ALL
5
RLY2038
ELECTRONIC CONTROL BEFORE SERIAL# F0600187510
ALL
6
RLY2044
DISPLAY BOARD
ALL
7
WTR2530
LOW WATER CUTOFF, MANUAL RESET (OPTIONAL) PRIOR TO H08H00211366
ALL
7
WTR30000
LOW WATER CUTOFF, MANUAL RESET (OPTIONAL) BEGINNING H08H00211366
ALL
7
WTR2528
LOW WATER CUTOFF, AUTO RESET (OPTIONAL) PRIOR TO H08H00211366
ALL
7
WTR30001
LOW WATER CUTOFF, AUTO RESET (OPTIONAL) BEGINNING H08H00211366
ALL
-
WTR2532
LOW WATER CUTOFF PROBE (OPTIONAL) PRIOR TO H08H00211366
ALL
-
WTR2222
LOW WATER CUTOFF PROBE (OPTIONAL) BEGINNING H08H00211366
ALL
-
WTR2533
LOW WATER CUTOFF BOOT (OPTIONAL) PRIOR TO H08H00211366
ALL
-
WTR20000
LOW WATER CUTOFF BOOT (OPTIONAL) BEGINNING H08H00211366
ALL
8
RLY2903
24V RELAY
ALL
9
TRF2010
TRANSFORMER 120VA
ALL
10
SWT2004
SWITCH
ALL
11
MSC2465
CIRCUIT BREAKER 5 AMP
ALL
12
RLY3058
RELAY/ PUMP
ALL
13
RLY2402
IGNITION MODULE
ALL
14
RLY2051
RELAY/ 10AMP
ALL
15
RLY2708
RELAY / 24VAC
ALL
16
RLY2714
ADJUSTABLE RELAY - OPTIONAL
ALL
17
SWT2006
SWITCH, ON/ OFF
ALL
18
HLC2702
MANUAL RESET HIGH LIMIT
ALL
19
PLT3400
HOT SURFACE IGNITOR
ALL
20
PRS2421
AIR PRESSURE SWITCH BEFORE SERIAL # A04
ALL
20
PRS2424
AIR PRESSURE SWITCH BEGINNING SERIAL # A04
ALL
21
HLC2510
HIGH LIMIT BEFORE SERIAL # F0600187510
ALL
21A TST2300
EMMEN BULBWELL BEGINNING SERIAL # F0600187510
ALL
-
TST2313
TEMPERATURE SENSOR, INLET/ OUTLET - NOT SHOWN
ALL
-
HLC2503
SWITCH, HIGH LIMIT, 110 DEGREES
ALL
HEAT EXCHANGER
22
HEX3012
HEAT EXCHANGER HLW (AFTER SERIAL F00)
501
22
HEX3013
HEAT EXCHANGER HLW (AFTER SERIAL F00)
651
22
HEX3014
HEAT EXCHANGER HLW (AFTER SERIAL F00)
751
22
HEX3016
HEAT EXCHANGER CUPRO NICKEL HLW (AFTER SERIAL F00)
401
22
HEX3017
HEAT EXCHANGER CUPRO NICKEL HLW (AFTER SERIAL F00)
501
22
HEX3018
HEAT EXCHANGER CUPRO NICKEL HLW (AFTER SERIAL F00)
651
22
HEX3019
HEAT EXCHANGER CUPRO NICKEL HLW (AFTER SERIAL F00)
751
22
HEX3402
HEAT EXCHANGER H (BEFORE SERIAL F00)
501
22
HEX3403
HEAT EXCHANGER H (BEFORE SERIAL F00)
651
22
HEX3404
HEAT EXCHANGER H (BEFORE SERIAL F00)
751
22
HEX3442
HEAT EXCHANGER H CUPRO NICKEL (BEFORE SERIAL F00)
501
22
HEX3443
HEAT EXCHANGER H CUPRO NICKEL (BEFORE SERIAL F00)
651
22
HEX3444
HEAT EXCHANGER H CUPRO NICKEL (BEFORE SERIAL F00)
751
23
JKD2252
V-BAFFLE (5 REQUIRED)
501
23
JKD2253
V-BAFFLE (5 REQUIRED)
651
23
JKD2254
V-BAFFLE (5 REQUIRED)
751
24
JKD6450
V-BAFFLE FRAME RUNNER (2 REQUIRED)
501
24
JKD6451
V-BAFFLE FRAME RUNNER (2 REQUIRED)
651
24
JKD6452
V-BAFFLE FRAME RUNNER (2 REQUIRED)
751
25
GKT2400
HEATSHIELD GASKET
ALL
26
JKD6186
V-BAFFLE FRAME END
ALL
27
GTP3000
TEMPERATURE GAUGE
ALL
NOTE: CP = POOL HEATER
PLEASE HAVE MODEL NUMBER AND SERIAL NUMBER WHEN ORDERING PARTS.
3 of 4
CP-RP-04
1
BNR3417 IS MAIN BURNER
BNR3416 IS MAIN BURNER W/
BARB PRESSURE TAP.
Model
BNR3416
BNR3417
501
1 ea
9 ea
651
1 ea
12 ea
751
1 ea
14 ea
