23
LEICA TRINOVID LEICA TRINOVID LEICA TRINOVID LEICA TRINOVID
10 x 42 BN 8 x 50 BN 10 x 50 BN 12 x 50 BN
Type of prism roof roof roof roof
Phase correction P 40 yes yes yes yes
Magnification 10 x 8 x 10 x 12 x
Entrance pupil (EP) 42mm 50mm 50mm 50mm
Exit pupil (AP) 4.2mm 6.25mm 5mm 4.2mm
Close-up range at 0 diopters 2.95m 3.60m 3.35m 3.25m
Field of view 110m/1000m 115m/1000m 115m/1000m 100m/1000m
(6.3°) wide angle (6.6°) (6.6°) wide angle (5.7°) wide angle
Overrun 1–4 dptr. 1–4 dptr. 1–4 dptr. 1–4 dptr.
Diopter compensation
for difference between
left and right eye
Ϯ4 dptr. Ϯ4 dptr. Ϯ4 dptr. Ϯ4 dptr.
Twilight factor 20.5 20.0 22.4 24.5
Geometric light value 17.6 39.1 25.0 17.6
Operational temperature –25° to +55°C –25° to +55°C –25° to +55°C –25° to +55°C
range –13° to 131°F –13° to 131°F –13° to 131°F –13° to 131°F
Storage temperature range –40° to +85°C –40° to +85°C –40° to +85°C –40° to +85°C
–40° to 185°F –40° to 185°F –40° to 185°F –40° to 185°F
Eyebase 56–74mm 58–74mm 58–74mm 58–74mm
Water pressure tight up to 0.5 bar up to 0.5 bar up to 0.5 bar up to 0.5 bar
(depth15m) (depth15m) (depth15m) (depth15m)
Height (with eyecups retracted) 1141mm 1181mm 1178mm 1182mm
Width* 1130mm 1135mm 1135mm 1135mm
Depth* 157mm 163mm 163mm 163mm
Weight 1890g 11150g 11150g 11150g
* (eyebase 65 mm)
