Linksys HM-BT-VIN User Manual
Page 8
ProComSol, Ltd
HM-BT-VIN User Manual
MAN-1006 4/07/2006
Page 8
Appendix I. Front Panel Connector Diagram
J1
Function
1
V+, Power Supply In
2
V-, Power Supply Ground
3
HART In+
4
HART In-
5
HART In+
6
HART In-
Notes:
1. Terminals 3 and 5 are connected together internally
2. Terminals 4 and 6 are connected together internally
