UTILITY SPECIFICATIONS REQUIRED – ELECTRIC
Model
Energy
Power
Voltage
Current
Phase
Hz
Recommended
Electrical Specification
Recommended
Circuit Breaker
Supply Wire
Size 90° C
Agency Listings
1130/60
Electric
10kW
120/208 VAC
48 Amps
1
60 Hz
4 Wires, 2 Pole + N + G
2 Pole, 50 Amp
6 AWG
UL, CSA, NSF
1131/61
Electric
10kW
120/240 VAC
42 Amps
1
60 Hz
4 Wires, 2 Pole + N + G
2 Pole, 50 Amp
8 AWG
UL, CSA, NSF
1132/62
Electric
10kW
120/208 VAC
28 Amps
3
60 Hz
5 Wires, 3 Pole + N + G
3 Pole, 30 Amp
10 AWG
UL, CSA, NSF
1133/63
Electric
10kW
120/240 VAC
25 Amps
3
60 Hz
5 Wires, 3 Pole + N + G
3 Pole, 30 Amp
10 AWG
UL, CSA, NSF
1130-080-A
Electric
10kW
120/208 VAC
48 Amps
1
60 Hz
4 Wires, 2 Pole + N + G
2 Pole, 50 Amp
6 AWG
UL, CSA, NSF
1131/61-080-A
Electric
10kW
120/240 VAC
42 Amps
1
60 Hz
4 Wires, 2 Pole + N + G
2 Pole, 50 Amp
8 AWG
UL, CSA, NSF
1132/62-080-A
Electric
10kW
120/208 VAC
28 Amps
3
60 Hz
5 Wires, 3 Pole + N + G
3 Pole, 30 Amp
10 AWG
UL, CSA, NSF
1133-080-A
Electric
10kW
120/240 VAC
25 Amps
3
60 Hz
5 Wires, 3 Pole + N + G
3 Pole, 30 Amp
10 AWG
UL, CSA, NSF
1134
Electric
10kW
380Y/208 VAC
15 Amps
3
50 Hz
5 Wires, 3 Pole + N + G
5 x 2.5mm
2
NSF
1135
Electric
10kW
415Y/240 VAC
14 Amps
3
50 Hz
5 Wires, 3 Pole + N + G
5 x 2.5mm
2
NSF
1136
Electric
10kW
240 VAC
42 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
3 x 10.0mm
2
NSF
1151
Electric
10kW
200VAC
29 Amps
3
60 Hz
4 Wires, 3 Pole + G
3 x 4.0mm
2
NSF
*1164-XXX-E
Electric
10kW
400/230 VAC
15 Amps
3
50 Hz
5 Wires, 3 Pole + N + G
3 Pole, 32 Amp
5 x 2.5mm
2
CE, NSF
1130-000-A
Electric
10kW
208 VAC
48 Amps
1
60 Hz
3 Wires, 2 Pole + G
2 Pole, 50 Amp
6 AWG
UL, CSA, NSF
1131-000-A
Electric
10kW
240 VAC
42 Amps
1
60 Hz
3 Wires, 2 Pole + G
2 Pole, 50 Amp
8 AWG
UL, CSA, NSF
1132-000-A
Electric
10kW
208 VAC
28 Amps
3
60 Hz
4 Wires, 3 Pole + G
3 Pole, 30 Amp
10 AWG
UL, CSA, NSF
1133-000-A
Electric
10kW
240 VAC
25 Amps
3
60 Hz
4 Wires, 3 Pole + G
3 Pole, 30 Amp
10 AWG
UL, CSA, NSF
1130-08H-A
Electric
12kW
208 VAC
63 Amps
1
60 Hz
3 Wires, 2 Pole + G
2 Pole, 90 Amp
4 AWG
UL, cUL, NSF
1131-08H-A
Electric
12kW
240 VAC
54 Amps
1
60 Hz
3 Wires, 2 Pole + G
2 Pole, 50 Amp
6 AWG
UL, cUL, NSF
1132-08H-A
Electric
12kW
208 VAC
36 Amps
3
60 Hz
4 Wires, 3 Pole + G
3 Pole, 70 Amp
8 AWG
UL, cUL, NSF
1133-08H-A
Electric
12kW
240 VAC
31 Amps
3
60 Hz
4 Wires, 3 Pole + G
3 Pole, 40 Amp
10 AWG
UL, cUL, NSF
* REF MODEL NUMBER KEY
UTILITY SPECIFICATIONS REQUIRED – GAS
Model
Energy
Power
Voltage
Current
Phase
Hz
Recommended
Electrical Specification
Recommended
Circuit Breaker
Gas
Agency Listings
1116
Nat. Gas
40,000 BTU
120 VAC
7 Amps
1
60 Hz
3 Wires, 1 Pole + N + G
1 Pole, 15 Amp
40,000 BTU at 7 inches, H
2
O column**
CSA, NSF
1117
L.P. Gas
40,000 BTU
120 VAC
7 Amps
1
60 Hz
3 Wires, 1 Pole + N + G
1 Pole, 15 Amp
40,000 BTU at 11 inches, H
2
O column**
CSA, NSF
1154
Nat. Gas
45 MJ
240 VAC
2 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
45 MJ/HR at 1.7 kPa, H
2
O column**
AGA*, NSF
1155
L.P. Gas
45 MJ
240 VAC
2 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
45 MJ/HR at 2.73 kPa, H
2
O column**
AGA*, NSF
1156
Town
45 MJ
240 VAC
2 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
45 MJ/HR at 3.6 kPa, H
2
O column**
AGA*, NSF
1157
Nat. Gas
40,000 BTU
220/240 VAC
2 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
40,000 BTU at 7 inches, H
2
O column**
NSF
1158
L.P. Gas
40,000 BTU
220/240 VAC
2 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
40,000 BTU at 11 inches, H
2
O column**
NSF
*1154-XXX-E
Nat. Gas
12kW
230 VAC
2 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
1 Pole, 16 Amp
12 kW/HR at 17.4 mB, H
2
O column**
CE, NSF
*1155-XXX-E
L.P. Gas
12kW
230 VAC
2 Amps
1
50 Hz
3 Wires, 1 Pole + N + G
1 Pole, 16 Amp
12 kW/HR at 27.4 mB, H
2
O column**
CE, NSF
1116-000-A
Nat. Gas
40,000 BTU
120 VAC
7 Amps
1
60 Hz
3 Wires, 1 Pole + N + G
1 Pole, 15 Amp
40,000 BTU at 7 inches, H
2
O column**
CSA, NSF
1117-000-A
L.P. Gas
40,000 BTU
120 VAC
7 Amps
1
60 Hz
3 Wires, 1 Pole + N + G
1 Pole, 15 Amp
40,000 BTU at 11 inches, H
2
O column**
CSA, NSF
1116-080-A
Nat. Gas
40,000 BTU
120 VAC
7 Amps
1
60 Hz
3 Wires, 1 Pole + N + G
1 Pole, 15 Amp
40,000 BTU at 7 inches, H
2
O column**
CSA, NSF
1117-080-A
L.P. Gas
40,000 BTU
120 VAC
7 Amps
1
60 Hz
3 Wires, 1 Pole + N + G
1 Pole, 15 Amp
40,000 BTU at 11 inches, H
2
O column**
CSA, NSF
GAS PRESSURE CONVERSION CHART
Inches of
Water Column
KPa
m-Bar
Millimeters of
Water Column
3.5
0.87
8.70
88.9
4.5
1.12
11.2
114.3
7
1.74
17.40
177.8
10
2.48
24.87
254.0
10.5
2.61
26.11
266.7
11
2.73
27.36
279.4
14
3.48
34.81
355.6
14.5
3.61
36.05
368.3
* AGA – Australia Gas Association (See 1154 & 1155 above)
** NOTE: For proper operation, the gas valve requires a nominal inlet pressure of 7 inches of H
2
O for natural gas and 11 inches of H
2
O column
for L.P. gas. A minimum inlet pressure of 1.0 inch of H
2
O column above the manifold setting (NAT. manifold 3.5” H
2
O, L.P. manifold 10” H
2
O)
must be maintained with no pressure drop from the no load to full load condition. The maximum inlet pressure must be maintained at or below
½ PSIG (14.5 inches H
2
O column). Refer to the chart on the left for pressure conversions.
Electrical Supply for Australia:
Single Phase: 240 VAC, 50 Hz / 20 Amp; one neutral & one earth/ground.
Three Phase: 240/415 VAC / 20 Amp; three active, one neutral & one earth/ground.
All ovens require separate service and dedicated neutral.
NOTE: Do not install the (these) oven(s) in any area with an ambient temperature in excess of 95°F / 35° C. Doing so will cause damage to the
unit.
