Linksys HomeLink™ Series
Specifications
Model Number: HPES03
Standards: IEEE 802.3 10BaseT, HomePNA v.1.1
Protocol: CSMA/CD
Ports: Two 10BaseT RJ-45, One Uplink RJ-45 (Shared),
One Modular Telephone RJ-11 (with Pass-
Through)
Speed: HomePNA - 1Mbps, Ethernet - 10Mbps
Cabling Type: Standard Telephone Cable, 10BaseT - Category 3
or 5 UTP or STP
Topology: Star (10BaseT) or Bus (HomePNA)
LED Status Lights: Link per Port, Activity per Port, Collision per Port,
Power
Environmental
Dimensions (LxWxH): 7.5” x 6” x 2”
Unit Weight: 0.9 lbs.
Power Input: 5V DC, 3A
Certifications: Class B, CE Mark Commercial
Operating Temperature: 32°F to 131°F (0°C to 55°C)
Storage Temperature: -4°F to 158°F (-20°C to 70°C)
Operating Humidity: 10% to 85% Non-condensing
Storage Humidity: 5% to 90% Non-condensing
12
