4f42, Architectural decorative, Features – Lightolier Architectural Decorative 4F42 User Manual
Page 2: Lamping (by others), Electrical, Mounting, Labels, Application data, Job information type
0-30
696
2.72
3.37
0-40
1147
4.48
5.56
0-60
2066
8.07
10.01
0-90
2898
11.32
14.04
40-90
1750
6.84
8.48
60-90
831
3.25
4.03
90-180
17747
69.33
85.96
0-180
20646
80.65
100.00
** EFFICIENCY = 80.6% **
ZONAL LUMENS AND PERCENTAGES
CERTIFIED TEST REPORT NO. 4A42842A
COMPUTED BY LSI PROGRAM **TEST-LITE**
LIGHTOLIER INDIRECT/DIRECT PENDANT FIXTURE
CAT. #4A42842A, HOUSING COVER WITHOUT FLANGE, 42” DIFFUSER
8-42W PLT TRIPLE TUBE PHILIPS LAMPS. LUMEN RATING = 3200 LMS.
4-OSRAM BALLASTS, #M2-CF-26/32/42-B-M-UNIV., 120 VAC
TESTED ACCORDING TO IES PROCEDURES. TEST DISTANCE EXCEEDS FIVE
TIMES THE GREATEST LUMINOUS OPENING OF LUMINAIRE.
C
ANDLEPOWER SUMMARY
DATE: SEPT. 15, 2000
PREPARED FOR:
LIGHTOLIER, FALL RIVER, MA
0
890
90
136
5
884
84
95
347
532
10
874
100
1122
15
856
242
105
1847
1900
20
831
110
2367
25
800
370
115
2832
2796
30
763
120
3237
35
721
452
125
3618
3234
40
672
130
3949
45
617
477
135
4137
3187
50
556
140
4240
55
493
442
145
4346
2737
60
429
150
4495
65
371
369
155
4491
2016
70
314
160
3947
75
261
277
165
3412
998
80
212
170
3313
85
166
186
175
3685
347
90
136
180
3859
ANGLE MEAN CP LUMENS ANGLE MEAN CP LUMENS
ROOM
CA
VITY
RA
TIO
COEFFICIENTS OF UTILIZATION ZONAL CAVITY METHOD
%EFFECTIVE FLOOR CAVITY REFLECTANCE = .20
80
70
50
30
10
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
1
.69 .66 .63
.60 .58 .55 .44 .43 .41 .30 .29 .28 .16 .16 .15 .08
2
.60 .55 .51
.52 .49 .45 .39 .36 .34 .26 .24 .23 .14 .13 .13 .07
3
.53 .47 .43
.46 .42 .38 .34 .31 .29 .23 .21 .20 .12 .12 .11 .06
4
.46 .40 .36
.41 .36 .32 .30 .27 .24 .20 .18 .17 .11 .10 .09 .05
5
.40 .35 .30
.36 .31 .27 .27 .23 .21 .18 .16 .14 .10 .09 .08 .04
6
.37 .30 .26
.32 .27 .23 .24 .20 .18 .16 .14 .12 .09 .08 .07 .04
7
.33 .27 .22
.29 .24 .20 .21 .18 .15 .15 .12 .11 .08 .07 .06 .03
8
.39 .29 .24
.26 .21 .17 .19 .16 .13 .13 .11 .09 .07 .06 .06 .03
9
.36 .27 .21
.23 .19 .15 .18 .14 .12 .12 .10 .08 .07 .05 .05 .02
10
.33 .24 .19
.21 .17 .13 .16 .13 .10 .11 .09 .07 .06 .05 .04 .02
DETERMINED IN ACCORDANCE WITH CURRENT IES PUBLISHED PROCEDURES
Features
1. Diffusing Reflector: White translucent acrylic, 3/16” thick.
2. Inner Dirt Shield: White translucent acrylic, 1/8” thick.
3. Chassis: Steel 20 gauge, semi-gloss white powder-coat finish.
4. Suspension: Swivel (central) stem, 5/8” steel tube. Canopy, steel, 7” Dia.
fastened internally, no exposed hardware. Permits installation on ceilings
with slope of up to 45°. Complies with California Code.
5. Multiple Stems: 3/8” Steel outer pipe stems surround center stem and go
into collector plate.
6. Lampholder: Multi-wattage, 4-pin, will accept either GX24q-3 or
GX24q-4 lamp base.
7. Flange Trim: Steel 20 gauge, Plated or Painted Finish.
Lamping (by others)
Compact Fluorescent: Triple Tube, 26, 32, or 42 Watts.
General Electric
Osram/Sylvania
Philips
26W Triple Tube 4-Pin (Amalgam) Compact Fluorescent Lamp
F26TBX/*/A/4P
CF26DT/E/IN/*
PL-T26W/*/4P
32W Triple Tube 4-Pin (Amalgam) Compact Fluorescent Lamp
F32TBX/*/A/4P
CF32DT/E/IN/*
PL-T32W/*/4P
42W Triple Tube 4-Pin (Amalgam) Compact Fluorescent Lamp
F42QBK/*/A/4P
CF42DT/E/IN/*
PL-T42W/*/4P
*Manufacturers’ color temperature designation.
Electrical
Ballast: Electronic, 2-Lamp HPF, Class P, Programmed Start.
Universal Voltage 120/277V, Multi-Wattage 26/32/42W.
8 Lamps
26 Watt
32Watt
42Watt
Voltage
120V
277V
120V
277V
120V 277V
Total Input Watts
224
224
276
276
364
364
Max. Line Current (amps) 1.84
0.8
2.32
1.04
3.04
1.28
Power Factor
>.98
>.98
>.98
>.98
>.98
>.99
Ballast Factor
1.02
1.02
1.00
1.00
0.98
0.98
THD<10% Minimum Starting Temperature 0°F /-18°C.
Mounting
Mounts directly to 4” outlet box, using crossbar hanger, supplied.
Labels
cULus listed suitable for damp locations.
Application Data
Reflectancies: 80% Ceiling, 50% Walls, 20% Floor.
Light Loss Factor = .75 (.88 BF x .85)
FC (footcandles) at 30” work plane.
42 Inch Diameter
45’ x 45’ x 12’ Space
Luminaire
Spacing: 15’ x 15’
Susp. Dist. 42”
8 Lamps
26W
32W
42W
TTT
TTT
TTT
Illum. (FC)
29
39
52
Maint.
Lum.
10/1
10/1
11/1
Ratio
Watts/
0.98
1.21
1.65
Sq. Ft.
Architectural Decorative
4F42
Page 2 of 2
Pendalux Gemini 42” Diameter Body 8-26/32/42 Triple Tube
Lightolier
a Genlyte company
www.lightolier.com
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • C0605
Job Information
Type:
