This is a simplified representation of the TV front panel, side panel control buttons and side inputs.
Introduction
Controls
1.MENU: Menu display.
2.INPUT: Press to
the input source mode.
3.VOL +/-: Press to adjust the volume. In the MENU screen, these buttons serve as left/right buttons.
4.CH +/- : Press to scan through channels. To scan quickly through channels, press and hold down
either +/- . In the MENU screen, these buttons serve as up/down buttons.
5.POWER: Press to turn on and off the TV.
6.
7.Av2 AUDIO IN: Connect the audio L/R cables from the video signal source to these jacks.
8.AV2 VIDEO IN: Connects the composite video cable from an external signal source to this jack.
9.Headphone jack : Headphone audio output terminal.
10.HDMI IN: Connect a
11. Remote Sensor Receives
signals from the remote control.
Do not put anything near the sensor ,
Press to access the on-screen menu display
access Press repeatedly to change the source to the one you want to
watch. In the MENU screen, the INPUT button serves as the ENTER button.
USB input: Connect a USB flash drive to view JPEG images or listen to MP3 songs.
IR
which may block the remote control signal.
HDMI device to receive digital audio and uncompressed digital video signals.
HL26K1/HL32K1/HL32XK1/HL42XK1
HL26R1/HL32R1/HL42XR1
L
-
AUDIO
-
R
L
-
AUDIO
-
R
HDMI4
IN
HDMI3
IN
USB
VIDEO2
IN
VIDEOVIDEO
MENU
INPUT
V
OL+
V
OL-
C
H+
CH-
POWER
MENU
INPUT
VOL+
VOL-
CH+
CH-
POWER
TV Side panel controls and connections
Owner s Manual 5
