58 Multi type Air Conditioner

1. Room Type Indoor Unit -S4/SE chassis

2. Art Cool Type Indoor Unit

Wiring Diagram

Schematic Diagram

3. Outdoor Unit
1. A3UH363FA0(LMU360HE)

2. A3UC363FA0(LMU360CE)
