A-1 INSTALLATION
GX 271 Chopper
A-1
TECHNICAL SPECIFICATIONS - Red-D-Arc GX-271 (K1623-1)
Make/Model Description Speed (RPM) Displacement Starting Capacities
System
Honda 2 cylinder High Idle 3700 37.7 cu. in 12VDC battery Fuel: 9.0 gal.
GX620 20.0 HP @ Low Idle 2400 (615 cc) (Group 58, 435 34 L
Gas Engine 3600 RPM Full Load 3400 cold crank amps)
Full Load Bore x Stroke Oil: 1.59 Qts.
20A. Battery 1.5 L
3.00” x 2.60” Charger
(77 mm x 66 mm)
INPUT - ENGINE
RATED OUTPUT - WELDER
HEIGHT WIDTH DEPTH WEIGHT
30.3 in. 19.1 in. 42.0 in. 469 lbs.
770 mm 485 mm 1067 mm 212 kg.
OUTPUT - GENERATOR
Welding Output Volts at Rated Amps Duty Cycle 1 Max. OCV @ 3700 RPM
CC Stick/TIG, Pipe and CV Wire Welding
275 Amps 28 volts 100%
80 volts DC
300 Amps 25 volts 60%
Auxiliary Power 2
8,000 Watts, 60 Hz
120/240 Volts
100 % Duty Cycle
42 Volt Auxiliary Power for Wire Feeders
PHYSICAL DIMENSIONS
1. Duty cycle is based on a 10 minute period. This machine can be loaded to 300 amps for 6 minutes out of every 10 minute
period.
2. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to
rated capacity. When welding, available auxiliary power will be reduced.
