Controls and connectors – Lenovo LXM-WL19CH User Manual
Page 5
CONTROLS AND CONNECTORS
Power cord
Connecting the power cord:
Connect one end of the DC cable to back of the
monitor and connect the other end to the computer.
SIGNAL CABLE
Connecting the Signal Cable:
Connect one end of the 15-pin D-Sub cable to
the back of the LCD monitor and connect the other end ot the computer’s D-
Sub port.
Figure 1 Connecting Cables
1. Power cord
2.
Signal Cable
5
