A-1 INSTALLATION
PRECISION TIG 275
A-1
TECHNICAL SPECIFICATIONS-PRECISION TIG 275 (K2618-1 Domestic Package*-60Hz)
(K2619-1 Domestic,K2619-2 Canadian-60Hz)
Voltage + 10%
208/230/460
460/575
Max. Amps With Out
Power Factor Capacitor
104/94/47
124/112/56
86/78/39
95/86/43
77/70/35
73/66/33
6/5/3
47/38
56/45
39/31
43/35
35/28
33/26
3/2
300W
Max. Amps With
Power Factor Capacitor
80/72/36
95/86/43
64/58/29
62/56/28
55/50/25
40/36/18
36/32/16
35/28
43/34
29/23
28/23
25/20
18/14
16/13
500W
Duty Cycle-Applications
40%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
60%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
100%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
Idle Amps
40%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
60%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
100%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
Idle Amps
Idle Power
RATED INPUT - SINGLE PHASE ONLY
K
Number
K2618-1
K2619-1
K2619-2
RATED OUTPUT - NEMA EW1 Class ll (40)
Duty Cycle-Applications
40%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
60%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
100%
AC/DC Stick / Balance TIG
Unbalance (70% Penetration # ) AC TIG
Volts at Rated Amperes
31.0
16.1
29.0
15.4
28.0
14.8
Amps
275
255
225
200
200
150
*Shown on Front of this IM manual with Under-Cooler Cart and Advanced Control Panel (Refer to Optional Equipment)
# Exceeds NEMA Unbalanced Load Specification comparable for Auto-Balance.
RATED POWER FACTOR (STICK) K2618-1,K2619-1 & K2619-2 .63 min. .85 min.
