22
APPENDIX
SPECIFICATIONS
Weight 343 lbs
Height 42"
Width 43"
Depth 26-5/8"
Chimney weight ASHT+ 8.75 lb/feet
Chimney weight S-2100+ 13.2 lb/feet
Chimney weight AC 3.75 lb/feet
CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a
safe installation :
Side wall:
18" (457mm)
Ceiling: 7 feet (2135mm)
measured from the base
of the fireplace
Fireplace enclosure: Bottom: 0"
Side: 0"
Back: 0"
Top: Do not fill the space
above the fireplace with
any material (7 feet
measured from the base
of the fireplace)
Chimney: 2" (50mm)
Mantel: 48" (1219mm) from the
base of the fireplace
ME43 COMPONENTS LISTS
Attic Radiation Shield, ACRSA H0487
Wall Radiation Shield, 30 , AC, RSM30 ACRSM30
Insulated Wall Radiation Shield, 30 , ACRSMI30 H0489
Chimney Outside Air Kit (Flex, Insulation, Outside
Register And Coupling), ACZI H1967
Notes: AC Chimney is Not recommended at elevations above 4000 feet
or in cold climates.
Replacement Parts
Description Part/Cat. No.
Refractory PR-SR2028
Back refractory PR-SR2027
Right side refractory PR-SR2025D
Left side refractory PR-SR2025G
Bottom refractory PR-SR1722
Front refractory ash lip PR-SR2026
Log Support Grate PR-HELS43
Top louver PR-SR15P
Bottom louver PR-SR15P
Louver hinges PR-PIVOT
Rigid firescreen (right) PR-PARETIND-1
Black door (left) PR-SR2060GNO
Black door (right) PR-SR2060DNO
Gold plated door (left) PR-SR2060GOR
Gold plated door (right) PR-SR2060DOR
Wooden handle PR-SAC#69
Ceramic glass panel PR-VC10
Snap disc, blower VTU
Door gasket assembly PR- GASKPORTEHE-1
Damper PR-DAMPER43
Touch-up paint, black 90L73
