Component assembly legend, Pshadse hip adduction – Life Fitness PSHADSE User Manual
Page 4
COMPONENT ASSEMBLY LEGEND
________________________________________
Page 4
ITEM NO.
QTY.
PART NO. DESCRIPTION
ITEM NO.
QTY.
PART NO. DESCRIPTION
1
1
7546901 WLDMT, PSHAB/HAD MAIN FRAME
32
1
7348001 LABEL, LIFE FITNESS LOGO
2
4
3237701 ASSY, PILLOW BLOCK 4.88 X 2.75
33
1
7422004 LABEL, 2" ASTM WARN
3
1
7551201 WLDMT, PIVOT ARM RIGHT PSHAD
34
1
7571301 LABEL, SERIAL NUMBER
4
1
7551401 WLDMT, PIVOT ARM LEFT PSHAD
35
4
3236214 SCREW, M10 X1.5 85MM
5
2
7352001 BUMPER, 2-1/8 X 4-5/8
36
4
3236203 SCREW, M10 X1.5 30MM
6
2
7551101 WLDMT, FOOT SUPPORT
37
3
7662801 RING, GRIP 1.25 OD
7
1
7551301 WLDMT, CAM PSHAD
38
12
3247701 M4 X .7 HXS NO CUP ST BO
8
1
7551501 WLDMT, ADJUST HANDLE PSHAD/HAB
39
3
3235801 GRIP, TBC
9
1
7549901 PIN, SPRING PSHAD/HAB
40
3
7662901 CAP, GRIP 1.25 OD
10
1
7353501 ASSY, 300LB STACK
41
5
3236902 NUT, M16 X 2 HEX JAM SS
11
2
7352101 CUSHION, WEIGHT STACK
42
2
3236201 SCREW, M10 X1.5 20MM
12
4
3237801 PULLEY, 4.5" OD
43
1
3236207 SCREW, M10 X1.5 50MM
13
41
3236601 WASHER, 3/8 SAE SS
44
1
7549201 LABEL, PSHAD PLACARD
14
2
3236206 SCREW, M10 X1.5 45MM
45
1
7549401 LABEL, PSHAD LOGO PANEL
15
1
3236209 SCREW, M10 X1.5 60MM
46
1
75495xx PAD, HIP ADDUCTOR LH
16
16
3236801 NUT, M10 HEX NYLOCK SS
47
1
75496xx PAD, HIP ADDUCTOR RH
17
1
7352401 CAP, END 2 X 4
48
1
3110011 ROLL PIN, 3/16 X 1-1/4
18
12
7544202 PAD, DUAL LOCK 250 1.5" X 2.0"
49
1
7351501 SPRING; PULL PIN LARGE
19
2
7606602 COVER, STACK-PRO2 STD
50
1
7570801 GUARD, PAINT 1.25"x.75"x.25"
20
2
7328614 GUIDE ROD, .75 OD SOLID 35.38
51
2
3236901 NUT, M10 X 1.5 JAM
21
2
7402301 RETAINER, GUIDEROD
52
2
7573701 CABLE, PSHAD/HAB
22
2
3232421 RING, BRE .940, 5100-100 ST PP B
53
1
7573801 WLDMT, PSHAD/HAB PULLEY BRKT
23
2
3240501 M10 X 1.5 HXS NO CUP ST BO
54
2
3236212 SCREW, M10 X1.5 75MM
24
4
7388201 FOOTPAD, PS RUBBER
55
17
3237401 PLUG, 7/16" HOLE
25
6
3238101 NUT, BLIND INSERT M10 X 1.5
56
1
7423712 CABLE, PSHAD/HAB
26
1
7324802 SHAFT, TAPPED 0.75 DIA X 1.800
57
1
7348101 WASHER, SPACER
27
2
3104901 .75" ID 1.00" OD BRONZE BUSHING
58
2
3104903 1.00" ID 1.25" OD BRONZ BUSHING
28
4
7352301 CAP, END 2 X 3
59
2
7422003 LABEL, MOVING PARTS
29
8
7352201 CAP, END 1-1/2 X 2
60
4
3251200 SCREW, M10 X1.5 X 35MM UNS HEX
30
12
3236204 SCREW, M10 X1.5 35MM
61
1
3237402 PLUG, HOLE
31
2
74221xx PAD, BACK 15 X 11-1/4
62
1
7806001 LABEL, PSHAD 1-9 CURVED
PSHADSE HIP ADDUCTION
