Lochinvar Copper-Fin2 CP 991-2071 User Manual
Page 3
ITEM
NO.
PART
NO.
DESCRIPTION
MODEL
NO.
BURNERS
GAS TRAIN ASSEMBLIES
2
ORF2421
ORIFICE, NAT
CPN991-2071
2
ORF2418
ORIFICE, LP
CPL991-2071
3
VAL2076
GAS VALVE, NAT
CPN991-2071
3
VAL2413
GAS VALVE, LP
CPL991-2071
CONTROLS & GAUGES
4
PAN3025
CONTROL PANEL BEGINNING SERIAL# F0600187510
ALL
4
PAN3012
CONTROL PANEL BEFORE SERIAL# F0600187510
ALL
5
RLY2904
ELECTRONIC CONTROL BEGINNING SERIAL# F0600187510
ALL
5
RLY2038
ELECTRONIC CONTROL BEFORE SERIAL# F0600187510
ALL
6
RLY2044
DISPLAY BOARD
ALL
7
RLY2402
IGNITION MODULE
ALL
8
WTR2530
LOW WATER CUT-OFF, MANUAL RESET (OPTIONAL) PRIOR TO H08H00211349
ALL
8
WTR30000
LOW WATER CUT-OFF, MANUAL RESET (OPTIONAL) BEGINNING H08H00211349
ALL
8
WTR2528
LOW WATER CUT-OFF, AUTO RESET (OPTIONAL) PRIOR TO H08H00211349
ALL
8
WTR30001
LOW WATER CUT-OFF, AUTO RESET (OPTIONAL) BEGINNING H08H00211349
ALL
-
WTR2532
LOW WATER CUT-OFF PROBE (OPTIONAL) PRIOR TO H08H00211349
ALL
-
WTR2222
LOW WATER CUT-OFF PROBE (OPTIONAL) BEGINNING H08H00211349
ALL
-
WTR2533
LOW WATER CUT-OFF BOOT (OPTIONAL) PRIOR TO H08H00211349
ALL
-
WTR20000
LOW WATER CUT-OFF BOOT (OPTIONAL) BEGINNING H08H00211349
ALL
9
RLY2903
24V RELAY / OTHER OPTIONS
ALL
10
RLY3058
RELAY PUMP/MAINT.
ALL
11
TRF2010
TRANSFORMER 120VA
ALL
12
SWT2004
SWITCH
ALL
13
MSC2447
CIRCUIT BREAKER 7AMP
ALL
14
RLY2708
24V RELAY
ALL
15
RLY2051
RELAY/ LOUVER
ALL
16
RLY2714
TIME DELAY RELAY
ALL
17
SWT2006
ON/ OFF SWITCH
ALL
18
HLC2702
MANUAL RESET HIGH LIMIT
ALL
19
PLT3400
HOT SURFACE IGNITOR
ALL
20
PRS2014
AIR PRESSURE SWITCH, NAT BEGINNING SERIAL # F05
CPN991-1261
20
PRS2013
AIR PRESSURE SWITCH, NAT & LP BEGINNING SERIAL # F05
CPN1441-2071 & CPL991-2071
20
PRS2422
AIR PRESSURE SWITCH, NAT BEFORE SERIAL # F05
CP991-1261
20
PRS2426
AIR PRESSURE SWITCH, NAT BEFORE SERIAL # F05
CP1441-2071
20
PRS2010
AIR PRESSURE SWITCH, LP BEFORE SERIAL # F05
CP991-2071
21
GTP3000
GAUGE, TEMPERATURE
ALL
-
HLC2503
SWITCH, HIGH LIMIT, 110 DEGREE
ALL
HEAT EXCHANGERS
22
HEX3000
HEAT EXCHANGER
CP991
22
HEX3001
HEAT EXCHANGER
CP1261
22
HEX3002
HEAT EXCHANGER
CP1441
22
HEX3005
HEAT EXCHANGER CUPRO NICKEL
CP991
22
HEX3006
HEAT EXCHANGER CUPRO NICKEL
CP1261
22
HEX3007
HEAT EXCHANGER CUPRO NICKEL
CP1441
22
HEX3008
HEAT EXCHANGER CUPRO NICKEL - STANDARD
CP1801
22
HEX3009
HEAT EXCHANGER CUPRO NICKEL - STANDARD
CP2071
23
JKE2004
V-BAFFLE
CP991
23
JKE2005
V-BAFFLE
CP1261
23
JKE2006
V-BAFFLE
CP1441
23
JKE2007
V-BAFFLE
CP1801
23
JKE2008
V-BAFFLE
CP2071
24
JKE6159
FRAME RUNNER
CP991
24
JKE6160
FRAME RUNNER
CP1261
24
JKE6161
FRAME RUNNER
CP1441
24
JKE6162
FRAME RUNNER
CP1801
24
JKE6163
FRAME RUNNER
CP2071
25
GKT2418
HEAT SHIELD GASKET
ALL
26
JKD6187
FRAME END
ALL
NOTE: CP = POOL HEATER
PLEASE HAVE MODEL NUMBER AND SERIAL NUMBER WHEN ORDERING PARTS.
3 of 4
CPE-RP-07
Model
BNR3423*
BNR3430**
BNR3422
991
1 ea
1 ea
10 ea
1261
1 ea
1 ea
13 ea
1441
1 ea
1 ea
15 ea
1801
1 ea
1 ea
19 ea
2071
1 ea
1 ea
22 ea
1
BNR3422 IS MAIN BURNER.
*BNR3423 IS MAIN BURNER W/ BARB PRESSURE TAP.
*BEFORE SERIAL # E05H00176040.
**BNR3430 IS MAIN BURNER W/ COMP. FTG. PRESSURE TAP.
**BEGINNING SERIAL # E05H00176040.
