Tools Required:
O
8mm Allen Wrench
O
17mm Wrench
O
Ratchet
O 3” Ratchet Extension
O
17mm Socket
O
8mm Hex Bit
Ab Crunch Bench
1. Assembly Instructions
Qty
1
1
13
21
12
1
1
2
1
1
1
5
12
1
1
1
2
1
1
1
Description
Lower Support
Cam Follower
Screw, M10 X 25mm
3/8” Flat Washer
Nylock Nut
Work Arm Stop
Cross Member
Screw, M10 X 135mm
Foot Rest
Back Support
Pad, Large Back
Screw, M10 X 35mm
1" Hole Plug
Pad, Arm Rest
Pad, Shoulder
Work Arm
Ball Bearing
Internal Spacer
3/8" Fender Washer
Bearing Housing Cap
Part Number
LEA78096XX
LEA78093XX
LEA3251702
LEA3102514
LEA3242002
LEA78099XX
LEA78097XX
LEA3251721
LEA78094XX
LEA78095XX
LEA74741XX
LEA3251704
LEA3237403
LEA73933XX
LEA74689XX
LEA78098XX
LEA3235601
LEA7799501
LEA3252001
LEA7308701
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
