System diagram, Owner’s manual 17, Equalizer with subwoofer crossover – Lanzar Car Audio E540P User Manual
Page 21: Left and right line inputs, Left and right line outputs from head unit, Rear channel speakers front channel speakers, Sub channel speakers sub channel power amplifier
owner’s manual
17
system diagram
4-Speaker and subwoofer system application using the E750s
Head unit (Stereo, CD Player, Tape Deck, etc.)
Lanzar Vibe E750s Equalizer & Crossover
REAR CHANNEL
Power Amplifier
FRONT CHANNEL
Power Amplifier
to Ground (Black)
to Remote On
(Orange)
to +12v Battery
(Red)
Left and Right
Line Inputs
Rear Panel
Left and Right
Line Outputs
from Head Unit
REAR CHANNEL
Speakers
FRONT CHANNEL
Speakers
Fuse: 1A
+12 Rem Gnd
INPUT
L
R
SUB
L
R
REAR
L
R
OUTPUT
FRONT
L
R
SUB CHANNEL
Speakers
SUB CHANNEL
Power Amplifier
E750s
LEFT output level
RIGHT output level
60Hz
–
+
150Hz
–
+
400Hz
–
+
1kHz
–
+
2.4kHz
–
+
6kHz
–
+
15kHz
–
+
0
+10dB
front
rear
fader
40 400
–
+
Subwoofer
equalizer with
subwoofer crossover
–
+
–
+
–
+
–
+
–
+
–
+
